GLASTONBURY

Glass Roof Potter

A statement in both design and detail. This premium glass-roof potter combines structural complexity with refined aesthetics, allowing light to pour in and transform your garden into a sophisticated, light-filled retreat.


Cladding: 12mm tongue & groove shiplap

Floor & Roof: 12mm tongue & groove matching

Framing: 32x44mm round corner framing

Glass: 3mm toughened glass

Ironmongery: Chrome; butt hinges, 3-lever lock and handle

Felt: Polyester roofing felt

Windows: Storm-proof windows, glass; front- (1) 1220mm x 610mm (2) 1220mm x 457mm (2) 906mm x 590mm (6ft)

(4) 1220mm x 457mm (2) 906mm x 590mm (7ft)

(2) 1220mm x 610mm (2) 1220mm x 457mm (2) 906mm x 590mm (8ft)

(3) 1220mm x 610mm (2) 1220mm x 457mm (2) 906mm x 590mm (10ft)

(3) 1220mm x 610mm (2) 1220mm x 457mm (2) 906mm x 590mm (12ft)

sides - 590mm x 905mm triangle

Joinery: Fully framed stable door 1765mm x 762mm

Internal fixings: Full length bench under window

External fixings: 12mm x 120mm fascias, window cill & door drip

Treatment: Water based brown treatment

Eaves height: 1854mm

Ridge height: 2058mm

Specification
